MAINTENANCE & TROUBLESHOOTING

To locate the diagnostic port on your Hy-Brid Lifts Pro Series machine, you'll need to remove the battery cover and two 7/16 in bolts. Next, slide out the lower control panel and locate the plug inside. Then, simply connect the plug to the EZcal Pro, and you're ready to go!

When we receive calls about machines, especially the HB-1430 or HB-1030 not elevating, the issue usually has something to do with the pothole plunger being bent. It’s a common wear and tear item that gets overlooked because it’s under the scissor stack. Here’s how to check your lift’s pothole plunger: This is a very easy fix — only a…

The HB Series 2 machines are some of the most popular Hy-Brid Lifts, but they can be tricky to master when it comes to their voltage readings. When troubleshooting these lifts, it’s much easier to identify your problem when you know what voltage each terminal is supposed to have—and what each terminal is responsible for. To keep…

The Hy-Brid Lifts EZcal Pro is an essential tool for troubleshooting and programming Hy-Brid Lifts. This tool is a must-have for every road technician and authorized service center that works on Hy-Brid Lifts. Handheld Size for Easy Transportation Keep one in every service vehicle and eliminate unnecessary trips to and from the shop. Diagnose Fault Codes Find service…

All Hy-Brid Lifts feature an LED display on the lower control board for error code diagnosis. By noting the number of times the light flashes between pauses, you can determine which error code is being presented, and take the necessary steps to fix the issue. Hy-Brid Lifts use a dual flash code, meaning two numbers…

During recent inspections, some washers used between the hub and retaining ring on the front casters of Hy-Brid Lifts Pro Series have shown premature wear. To address this, Custom Equipment is offering a Washer Upgrade Kit (Part #112-21-558-50-K) for lifts manufactured prior to May 2022. We recommend inspecting all affected MEWPs immediately. Signs of wear…

The purpose of this Operations and Safety manual is to provide users with the instructions and operating procedures essential to properly and safely operate the Hy-Brid Lift for its intended purpose, and to position personnel and their necessary tools and materials.

The purpose of this Maintenance Manual is to provide qualified service personnel with information for servicing and maintaining Hy-Brid Lifts. All information in this manual must be read and understood before any attempt is made to service this machine.
